| Specification | Description |
|---|---|
| NOTE: These are Preliminary Specifications | |
| NOTE: These are Preliminary Specifications | |
| Swing Over Bedways | 18" |
| Swing Over Cross Slide | |
| Distance Between Centers | 80" |
| Spindle Speeds (16) | 27 - 1100 RPM |
| Spindle Bore | |
| Spindle Nose | L Type |
| Feed Range | |
| Longitudinal | |
| Cross | |
| Inch Threads | Yes |
| Metric Threads | Yes |
| Tailstock Quill Diameter | |
| Tailstock Taper | |
| Tailstock Quill Travel | |
| Cross Slide Travel | |
| Bed Width | |
| Motor | |
| Floor Dimensions | 120" x 42" x 60" |
| Weight | 5500 lbs |
