| Specification | Description |
|---|---|
| Depth of Throat | 30" |
| Open Height | 36" |
| Bed Size (L-R x F-B) | 48" x 60" |
| Vertical Ram Platen | 24" x 24" |
| Vertical Ram Cylinder Size (approx) | 12" - 14" |
| Vertical Ram Stroke | 24" + |
| Horizontal Ram Platen (L-R x High | 24" x 16" |
| Horizontal Ram Size (approx) | 7-1/2" |
| Horizontal Ram Stroke | 48" + |
| Dimensions (F-B x L-R x H) | 11' x 5'2" x 13'8" |
| Oil Tank Capacity | 125 gallons |
| Oil Operating Pressure | 2,470 psi |
| Motor 220/440/60/3 | 25 HP |
| Overall Dimensions (L-R x F-B x H) | 5'6" x 12' x 13'8" |
| Shipping Dimensions (W x H x L) | 6' x 11' x 14' |
| Weight (approx) | 40,000 lbs |
