| Specification | Description |
|---|---|
| Punching Capacity | 90 Ton |
| Throat Depth | 12" |
| Flat Bar Shear | 24" |
| Shear Capacity | 1" x 8"; 3/4" x 12; |
| 1/2" x 16"; 1/4" x 24" | |
| Optional Sabre Shear Blade | 1/2" x 22"; 3/8" x 22" |
| Angle Shear at 90 degree | 6" x 6" x 1/2" |
| Angle Shear at 45 degree | 3" x 3" x 3/8" |
| Angles in Bar Shear at 45 degree | 4" x 4" x 1/2" |
| Strokes Per Minute (1/4" stroke) | 37 SPM |
| Strokes Per Minute (3/4" stroke) | 24 SPM |
| Motor (3 phase) | 5 HP |
| Dimensions (LxWxH) | 76" x 28" x 70" |
| Weight | 3,900 lbs |
